DP-637T Airless Spray tips

DP-637TT  Reversible Airless tips & tip gasket combo kit
Stainless steel shank + Tungsten carbide orifice
Nylon + stainless steel tip gasket, Durable and easily reversed for cleaning.
Tip Shank Diameter: 11.1mm
Max.5000 PSI (345 BAR)
This tip could fit , , etc. Most kind of airless guns.
Guaranteed perfect quality, fine atomization. Over 5000 m2 lifetime.
Tip size available: from 0.011" to 0.027" (2xx to 6xx)

DP-637T5  Reversible Airless tips & tip gasket combo kit
Airless tip in RAC V type, used for old guns.
Stainless steel shank + Tungsten carbide orifice
Nylon + stainless steel tip gasket, Durable and easily reversed for cleaning.
Tip Shank Diameter: 11.1mm
Max.5000 PSI (345 BAR)
Tip size available: from 0.011" to 0.035" (2xx to 6xx)

DP-637TX  Reversible Airless tips & tip gasket combo kit
Airless tip in RAC X type, used for new contractor guns.
Stainless steel shank + Tungsten carbide orifice
New material tip gasket, for easily reversed for cleaning.
Tip Shank Diameter: 11.4mm
Max.5000 PSI (345 BAR)
Guaranteed perfect quality, fine atomization. Over 5000 m2 lifetime.
Tip size available: from 0.011" to 0.027" (2xx to 6xx)

DP-637TW  Reversible Airless tips & tip gasket combo kit
Stainless steel shank + Tungsten carbide orifice
Nylon + stainless steel tip gasket, Durable and easily reversed for cleaning.
Tip Shank Diameter: 11.1mm
Max.5000 PSI (345 BAR)
This tip could fit , , etc. most kind of airless guns.
Tip size available: from 0.011" to 0.031" (2xx to 6xx)

DP-637TP  High pressure Airless tips & tip guard combo kit
High pressure airless tips & safety guard for pneumatic airless system
Max.7250 PSI (500 BAR)
Thread size: 7/8", M16*1.5 or 11/16"

DP-637G Tip gasket / tip seal (stainless steel + nylon)

DP-637FN Flat nozzle and filter for old machines

Orifice Size	Fan Width - Inches					Flow Rate		Application	Filter
inch	4” – 6” Fan	6” – 8” Fan	8” – 10” Fan	10” – 12” Fan	12” – 14” Fan	gpm	L/min
0.011”	211	311	411	511	611	0.12	0.45	Stain or Lacquer	150mesh (red)
0.013”	213	313	413	513	613	0.18	0.68
0.015”	215	315	415	515	615	0.24	0.91	Oil Base Paint	100mesh (yellow)
0.017”	217	317	417	517	617	0.31	1.17	Latex Paint / Acrylic / Enamel	100mesh
0.019”	219	319	419	519	619	0.38	1.44		60mesh (white)
0.021”	221	321	421	521	621	0.47	1.78
0.023”	223	323	423	523	623	0.57	2.16	Heavy latex	60mesh (white)
0.025”	225	325	425	525	625	0.67	2.54
0.027”		327	427	527	627	0.77	2.91
0.029”		329	429	529	629	0.90	3.41	Elastomeric / Blockfiller / Primer /	30mesh (green)
0.031”		331	431	531	631	1.03	3.90
0.033”		333	433	533	633	1.17	4.43
0.035”		335	435	535	635	1.31	4.96
